Opened 10 years ago
Last modified 6 years ago
#11565 needs_work enhancement
RSA Cryptosystem
Reported by:  ajeeshr  Owned by:  mvngu

Priority:  major  Milestone:  sage6.6
Component:  cryptography  Keywords:  RSA, crypto, public key encryption
Cc:  nguyenminh2@…  Merged in:
Authors:  Peter Story, Ajeesh Ravindran  Reviewers:
Report Upstream:  N/A  Work issues:
Branch:  u/peter.story/rsa_cryptosystem (Commits, GitHub, GitLab)  Commit:  c45c4dd7966114639a5d39b1e526729235d14e7a
Dependencies:  Stopgaps:
Description (last modified by )
The Rivest, Shamir and Adleman encryption system is a widely accepted public key encryption scheme. The security depends on the difficulty of factoring the product of large primes.
Attachments (2)
Change History (28)
Changed 10 years ago by
comment:1 Changed 10 years ago by
 Component changed from PLEASE CHANGE to cryptography
 Owner changed from tbd to mvngu
comment:2 Changed 10 years ago by
 Description modified (diff)
 Milestone changed from sage4.7.2 to sage4.7.1
comment:3 Changed 10 years ago by
well done, keep working
comment:4 Changed 10 years ago by
 Description modified (diff)
comment:5 Changed 10 years ago by
Just a few quick observations:
 What is the intended use of the code one included in Sage? If it's for teaching you would probably want to expose more of the details. In fact, for educational purposes it's probably better to do the whole construction "in the open" instead of wrapping it in a class, unless the educational part is wrapping things in classes. For actual cryptographic use, one would probably prefer a whole protocol library. The algorithm is a very small part of deploying cryptography in a secure manner.
 In your code you call
euler_phi(n)
to compute the private key d from e. Since the public key is (n,e), anyone could do that same calculation. That means that if it is doable for you to compute the private part of the key, then it is also doable for anyone. You don't have an advantage. (HINT: the key is that euler_phi computes the factorisation of n. If you would make sure that 2p1 and 2q1 are actually prime, you would know the factorization of n and hence euler_phi(n). But you should not call euler_phi(n), because that throws away your advantage).
comment:6 Changed 10 years ago by
Thank you nbruin. This was a valid information for me. I will correct it very soon. Keep supporting me in future also
comment:7 Changed 8 years ago by
 Milestone changed from sage5.11 to sage5.12
comment:8 Changed 8 years ago by
 Milestone changed from sage6.1 to sage6.2
comment:9 Changed 7 years ago by
 Milestone changed from sage6.2 to sage6.3
comment:10 Changed 7 years ago by
 Milestone changed from sage6.3 to sage6.4
comment:11 Changed 7 years ago by
I've rewritten ajeeshr's original module, to address nbruin's concerns and to have an implementation that is simpler and better suited for teaching. In summary, I made the following changes:
 Eliminated calls to euler_phi. These were unnecessary, because we know the primes, and $\phi(pq) = (p1)*(q1)$.
 Made primality checks optional (but enabled by default).
 Combined the methods that generate public and private keys into a single method, calculate_keys. This is more representative of how actual keygen programs are used.
 Stopped using Mersenne Primes. The original author seems to have been using them to allow the encoding of large messages, but I don't think this is necessary for a teaching module.
 Added more accessible references.
comment:12 Changed 7 years ago by
Hi! Can you make this a branch on the Trac serve with the git workflow? Also, what connection will this have to the (thus far) only currently implemented public system in that folder in Sage? Finally, should this be globally imported, or imported the way that one is? Thanks!
comment:13 Changed 7 years ago by
 Branch set to u/peter.story/rsa_cryptosystem
comment:14 Changed 7 years ago by
 Commit set to 4b667369410afa8400b009b8f4f5cc0ad968c78c
In the associated branch, I've added RSACryptosystem to the global namespace. Is there any reason why this is a bad idea?
BlumGoldwasser, the public key system already included with Sage, has a very similar API to RSACryptosystem. There are a few differences:
 In RSACryptosystem, I combined the
public_key
andprivate_key
methods into a singlecalculate_keys
method. This is because the exponente
would have had to be calculated independently (and identically) in the two methods. In BlumGoldwasser, the keys can more naturally be calculated independently.  I am missing a
random_key
method. This would be an easy addition, but I'm not sure how valuable it is; for RSACryptosystem it would only need to find two primes, and plug them intocalculate_keys
.
BlumGoldwasser doc: http://www.sagemath.org/doc/reference/cryptography/sage/crypto/public_key/blum_goldwasser.html
comment:15 Changed 7 years ago by
comment:16 Changed 7 years ago by
 Description modified (diff)
comment:17 Changed 7 years ago by
 Milestone changed from sage6.4 to sage6.6
 Status changed from new to needs_review
Presumably rather 6.7, but there's no new milestone yet.
By definition, factoring large primes is exceptionally easy... ;)
comment:18 Changed 7 years ago by
 Description modified (diff)
Haha, good catch! Changed the description to "factoring the product of large primes."
comment:19 Changed 7 years ago by
 Status changed from needs_review to needs_work
 If
__init__
is empty, you can just avoid it.
 What is the point of having the comparison implemented?! Moreover, the way you did is completely wrong
+ if self.__repr__() == other.__repr__(): + return True
The following will returnTrue
sage: rc1 = RSACryptosystem() sage: a = str(rc1) sage: rc1 == a
 In the function
encrypt
in the sectionTESTS
you repeat many times the definition ofrc
as well as the computation of the keys. Just remove all these duplication.
comment:20 Changed 7 years ago by
Before people spend too much time on the code here: Is there a reasonable scenario that justifies having this in the library? We're not going to use it for industrial encryption applications, so I think people think it's for teaching. However, when I teach RSA, the students have to *see* the exponentiation and the construction of the moduli. At that point, the fact that you can do squareandmultiply to do the exponentiation efficiently is already a worthwhile revelation for them.
So having that all wrapped up in library routines is no help at all. They're going to have these things in front of them on a worksheet.
Do people have some lower level scenario in mind where it's sufficient for the students to play around with a crypto "black box"?
I don't mind if it gets included for a good reason, but if the code here isn't going to be used properly and frequently in teaching I'd rather not have it in there, because it will take away from the excitement that students get from implementing their own RSA if there's already such an implementation available in sage.
comment:21 Changed 7 years ago by
Trivial comment: a number of things in the documentation are marked as code
``561=3*11*17``
that should probably be marked as math markup
`561=3*11*17`
or something along those lines.
Nils' argument presumably applies to nearly all the stuff in the crypto
folder, though, doesn't it? Certainly the only current publickey one.
I guess it depends on whether you are going to ask students to code things like DH or RSA, or only to "do" them. For my own purposes, I think it could be useful to have a wellcommented implementation of this (assuming this is in fact a wellcommented implementation) that could be used by any given instructor who may not want to/have the expertise to implement something well. (Mathematicians, not programmers.)
That said, I agree that the utility of this is clearly as a pedagogical tool, so a lot of examples of it (and/or why RSA could fail to be particularly secure with some choices of p
and q
, etc.) along with examples of "bruteforce" or other attacks would seem to be the main use of this. So that one can demonstrate such things without having to recode it all from scratch  builtin, as it were.
comment:22 Changed 7 years ago by
 Commit changed from 4b667369410afa8400b009b8f4f5cc0ad968c78c to 3c8e43ae07f14dbc6c42f42c5e91cfee5b3f2e45
Branch pushed to git repo; I updated commit sha1. New commits:
3c8e43a  Corrected the implementation of ``__eq__``.

comment:23 Changed 7 years ago by
@vdelecroix, thanks for bringing the __init__
and __eq__
methods to my attention. I copied the implementations from ajeeshr, who had copied them from BlumGoldwasser
, the other PublicKeyCryptosystem
. The reason BlumGoldwasser
implements them is to override the PublicKeyCryptosystem
implementations, which is necessary because BlumGoldwasser
doesn't initialize its superclass properly (it may be helpful to read the code for the Cryptosystem class's __init__
and __eq__
, which can be found on lines 104212 in cryptosystem.py).
I modified __eq__
to fix the issue you identified. Now, the method just compares the class of the two objects being compared. This is a change that should also be made to BlumGoldwasser
.
However, __init__
will be trickier to fix properly. According to the Cryptosystem
class, which RSACryptosystem
inherits through PublicKeyCryptosystem
, I should be passing the following arguments to my superclass's __init__
method: plaintext_space, ciphertext_space, key_space, block_length=1, period=None
. Without fixing this, inherited methods like the following will fail:
sage: rc = RSACryptosystem() sage: rc.key_space() AttributeError: 'RSACryptosystem' object has no attribute '_key_space'
The following values seem to make the most sense to me, but I'm not certain:
 plaintext_space = group of all integers
 ciphertext_space = group of all integers
 key_space: I have no idea how to specify this one as a group.
Ideally, I would give plaintext_space and ciphertext_space as integers mod n, instead of the group of all integers. However, this would require giving the RSACryptosystem class state, recording public and private keys internally. This would have the effect of making it more opaque, since users wouldn't need to explicitly pass keys to encrypt and decrypt. Thus, I think it makes sense to keep plaintext_space and ciphertext_space as the groups of all integers. Comments on this would be appreciated.
Side note: __init__
will also need to be fixed in BlumGoldwasser
:
sage: from sage.crypto.public_key.blum_goldwasser import BlumGoldwasser sage: bs = BlumGoldwasser() sage: bs.key_space() AttributeError: 'BlumGoldwasser' object has no attribute '_key_space'
Also, as suggested by kcrisman, I corrected several formatting issues with the documentation. Thanks to vdelecroix, I removed unnecessary redeclarations of variables in my tests, except where redeclaring improved readability.
comment:24 Changed 6 years ago by
A few comments on this:
 You can open a separate ticket for the
BlumGoldwasser
stuff, no need to fix it here.  You should use the
TestSuite
functionality, I guess, to ensure that all such possible errors are caught.  One possible option would be to make those spaces be
NotImplementedError
or something, and then document it as such.  Another one is that, considering
class PublicKeyCryptosystem(Cryptosystem): r""" The base class for asymmetric or publickey cryptosystems. """
is the entirety of the constructor forPublicKeyCryptosystem
, and that several of the systems in thecrypto/
folder don't even inherit fromCryptosystem
, one could just ignore this altogether and not inherit from it if there seems to be no reason to.  Or you could use integers.
 Or you could build it in but then
RSACryptosystem(n)
would be needed. That's sort of like how the other ciphers require you to put in the alphabet, so it isn't totally farfetched.
comment:25 Changed 6 years ago by
Of the options you described, I think the best is simply to not inherit from PublicKeyCryptosystem
or Cryptosystem
. If I inherit from either of them, implementing the plaintext_space
, ciphertext_space
, etc. would require accepting p
and q
when an RSACryptosystem
object is initialized. However, since this is a pedagogical module, that is undesirable, since I want to keep calculate_keys(p, q)
explicit.
Consequently, in this next patch I have removed inheritance from PublicKeyCryptosystem
.
comment:26 Changed 6 years ago by
 Commit changed from 3c8e43ae07f14dbc6c42f42c5e91cfee5b3f2e45 to c45c4dd7966114639a5d39b1e526729235d14e7a
Branch pushed to git repo; I updated commit sha1. New commits:
c45c4dd  Stopped inheriting from PublicKeyCryptosystem.

This is the python code I implemented in python. Just copy this into the public_key folder in crypto, import the class in this code into all.py in the public_key and rebuild sage and run it in a worksheet, its simple!!!
